Atul Engineering Graphics

Engineering Graphics – Diploma Semester 1 by Prof. P. J. Shah and Vaibhav P. Shah is an English-medium engineering textbook published by Atul Prakashan, Ahmedabad, prepared according to the revised syllabus of Gujarat Technological University (GTU).

The book is designed for first-semester Diploma Engineering students and develops the fundamental drawing and visualization skills required in technical education.

Its syllabus-oriented coverage includes important Engineering Graphics concepts such as engineering drawing fundamentals, lines and lettering, dimensioning, scales, geometrical constructions, projection of points and lines, projection of planes and solids, orthographic projection and isometric projection. Current diploma syllabi independently show these as core Engineering Graphics topics

• Publication
  Atul
• Publication Year
  2026
• Edition
  Latest
• Author
  Prof. P. J. Shah
• Content
  Descriptive
• Color
  Black and White
• Language
  English
• Binding
  Paperback
• Total Pages
  308
